SHENZHEN GLARE-LED OPTOELECTRONIC CO., LTD sales@glareled.com 86-755-29168291-881
Product Details
Place of Origin: Guangdong, China
Brand Name: Glare-LED
Model Number: GLG-LCS-600A
Payment & Shipping Terms
Price: Negotiable
Application: |
Outdoor, LED Lane Control/Message |
Type: |
LED |
Color: |
Dual-color, R: 620 To 630nm G : 500 To 530nm Y : 585 To 595nm |
Panel Size: |
400*400/600*600, 400*400/600*600 |
Supplier Type: |
Original Manufacturer |
Media Available: |
Datasheet, Photo |
Use: |
LED Lane Control/Message |
Pixel Pitch: |
Other, Other |
Specification: |
600*600, 400*400 |
HS Code: |
8531200000 |
Resolution: |
600*600 |
Usage: |
Outdoor |
Pixel Selection: |
Red/amber/green/etc |
Product Size: |
400*400/600*600 |
Consumption: |
30W |
Load: |
En 12899-1 : 2007 |
Flexure: |
En 12899-1 : 2007 |
Visible Flashing Rate: |
>90Hz |
IP Rate: |
IP65 |
Visual Angle: |
30° |
Application: |
Outdoor, LED Lane Control/Message |
Type: |
LED |
Color: |
Dual-color, R: 620 To 630nm G : 500 To 530nm Y : 585 To 595nm |
Panel Size: |
400*400/600*600, 400*400/600*600 |
Supplier Type: |
Original Manufacturer |
Media Available: |
Datasheet, Photo |
Use: |
LED Lane Control/Message |
Pixel Pitch: |
Other, Other |
Specification: |
600*600, 400*400 |
HS Code: |
8531200000 |
Resolution: |
600*600 |
Usage: |
Outdoor |
Pixel Selection: |
Red/amber/green/etc |
Product Size: |
400*400/600*600 |
Consumption: |
30W |
Load: |
En 12899-1 : 2007 |
Flexure: |
En 12899-1 : 2007 |
Visible Flashing Rate: |
>90Hz |
IP Rate: |
IP65 |
Visual Angle: |
30° |
product size | 400*400 / 600*600 |
cabinet material | Aluminum or iron |
load | EN 12899-1 : 2007 |
flexure | EN 12899-1 : 2007 |
impact force | passed |
vibratory force | passed |
passive safety | EN12767 |
brightness | R ≥3100 cd/m² G ≥3700 cd/m² Y ≥7400 cd/m² |
brightness ratio | R ≥4.2 G ≥5 Y ≥10 |
color | R : 620 to 630nm G : 500 to 530nm Y : 585 to 595nm |
visual angle | 30° |
homogeneity | Uniformity |
Visible flashing rate | ≥90Hz |
input voltage | 230Vac±15%, 50Hz |
electrical safty | HD 60364-4-443 and HD 638 S1 |
consumption | 30W |
operating temperature | -25ºC to +60ºC |
operating humidity | Up to 95% |
IP rate | IP65 |
anti-corrosion | D3, D4 |
conduction | EN50293 |
radiation | EN50293 |
interface | RS232, RS485, Ethernet, GPRS, 3G |
brightness control | 256 level automatic adjustment |
LED Single point detection | Open circuit and short circuit |
sensor | Temperature sensor, humidity sensor |
